Key Features
- High Efficiency up to 97.5% with single
MPPT tracker
- Low Start-up Voltage: 80V for optimal
low-light performance
- Zero Export Application for managing
self-consumption
- VSG Application for grid voltage support
- Optional String Intelligent Monitoring for
system diagnostics
- Wide Output Voltage Range compatible with
multiple grids
- Anti-PID function to prevent power
degradation (optional)
- Comprehensive Protection: DC reverse
polarity, AC overcurrent/overvoltage, short circuit, thermal & surge
protection
- Multiple Monitoring & Communication
Interfaces: GPRS/WIFI/Bluetooth/4G/LAN, RS485/RS232
Technical Specifications
| Parameter |
1kW |
1.5kW |
2kW |
2.2kW |
2.5kW |
2.7kW |
3kW |
3.3kW |
3.6kW |
4kW |
| Max. PV Input Power (kW) |
1.3 |
2 |
2.6 |
2.9 |
3.3 |
3.5 |
3.9 |
4.3 |
4.7 |
5.2 |
| Max. PV Input Voltage (V) |
550 |
| Start-up Voltage (V) |
80 |
| MPPT Voltage Range (V) |
70-500 |
| Rated PV Input Voltage (V) |
360 |
360 |
360 |
360 |
360 |
360 |
360 |
360 |
360 |
420 |
| Max. Operating PV Input Current (A) |
20 |
| Rated AC Output Power (kW) |
1 |
1.5 |
2 |
2.2 |
2.5 |
2.7 |
3 |
3.3 |
3.6 |
4 |
| Rated AC Output Current (A) |
4.6 |
6.8 |
9.1 |
10 |
11.4 |
12.3 |
13.7 |
15 |
16.4 |
18.2 |
| Rated Output Voltage (V) |
220/230 |
| Max. AC Output Apparent Power (kVA) |
1.1 |
1.65 |
2.2 |
2.42 |
2.75 |
2.97 |
3.3 |
3.63 |
3.96 |
4.4 |
Why Choose This Inverter?
Choosing our single phase string inverter in Nagpur ensures
high efficiency, reliable performance, and long-term protection for your solar
panels. As the trusted string inverter dealer in Nagpur, APC
Corp India provides professional installation, maintenance, and repair services.
Get your string inverter installed in Nagpur today and optimize
your solar energy system with the best solar panel installation company
in Nagpur.
Looking for the best string inverter installer in
Nagpur? Contact APC Corp India for a free consultation today!
